Features
■ We use A grade monocrystalline solar cell to gain the max. solar energy. High efficiency solar panel can ensure fast charging.
■ High quality deep cycle LiFePO4 lithium battery with over 2,000 lifecycles inside.
■ Branded LED chips(Epistar, Cree) privide quality lighting.
■ Remote control, PIR Sensor, when people is approaching, the light will turn to 100% power, when nobody detected, the light will work in 30% power.
■ Smart controller built in, automatic wake up function, light control and time control.
■ No trenching, no cabling, easy installation, labor cost saver.
Product specifications
| Parameters of 80W LED solar street light | |
| Solar Panel | 36V/130W Monocrystalline Solar Panel,Grade A |
| LED of pir sensor solar street light | 80W, 40*40mil Epistar Chip |
| Lifespan of LED | More Than 50,000 Hours |
| Luminous Flux | 8800lm~9600m |
| Color Temperature | 3000K~7500K |
| Beam Angle | 65°*130° |
| Battery | 24V, 40AH Li-ion lithium battery or 25.6V 30AH LiFePO4 Lithium Battery |
| Discharging Time | 18h (100% power), 42h (energy saving mode) |
Charging Time | 10h(AM1.5,1000W/m2,25℃) |
| Material | 6063 Aluminum,PC |
| Working Temperature | -25℃~55℃ |
| Diameter of Mounted Lamppost | 76~89mm |
| Mounting Height | 6~9m |
| Mounting Space | 20~30m |
| Packing Size | 1470*625*265mm |
| Net Weight | 33KG |
| Gross Weight | 42.4KG |
| Control Mode | Light, time and PIR remote control |
| Package Quantity | 112 sets/20' GP, 272 sets/40' GP |
Certificates
Application Areas
Pir sensor solar street light is widely used in public areas and residential areas as follows
▲ Road and street
▲ Office buildings
▲ Gardens, parks
▲ Residential areas
It can provide the friendly lighting while beautify the environment.
FAQ
1. How many hours can the pir sensor solar street light?
Normally, after fully charged, the light can work ≥18h(100% power). PIR contrlo:100% power when people approaching,, 30% power if nobody passes.
2. How many rainy days can the pir sensor solar street light work?
The light can work for 2~3 rainy days.
3. Is the battery replaceable?
Yes. The battery inside is easy to install. Normally, the lifetime of the LiFePO4 lithium battery is 2,000 cycles,≈5 years.
If the battery broken during the warranty period, we will offer you free replacement, and you need to relace the battery under guidance.
4. How does the pir sensor solar street light work?
The light is fully antuomatic light control. During the daytime, the solar panel will gain the power from the sun and charge the battery, when night comes, the light will automaticlly turn on, the battery inside
will provide the energy to the light.
5. Can we buy samples?
Yes. Please contact with our sales for sample order conditions. We will recommend you the suitable models according to your areas.
6. What's your warranty?
We provide 3 years warranty for compelet set of pir sensor solar street light. Free replacement will offer during the warranty period.
Our Factory
We own over 4,000 square meters of workshop, in year 2017, we have rebuilt our workshop due to the expansion of production line.
Our factory has passed the factory inspection by SGS.
